霍尼韦尔CT40 XP盘点手持终端介绍
霍尼韦尔CT40 XP盘点手持终端是honeywell Dolphin CT40的升级款,CT40 XP基于honeywell的 Mobility Edge™ 平台构建,是一款智能多功能企业级移动解决方案,采用坚固耐用的设计,可提高生产率,提供更长的生命周期和更好的安全性。honeywell CT40 XP与霍尼韦尔很新的 FlexRange™ 成像器集成后,可以捕获从几厘米到十米(32.8英尺)的零售好层货架条形码。它外形小巧轻便,配备一个 8 兆像素的前置相机。配备 1920 x 1080 像素的全高清显示屏,可用于团队培训、远程检测等。CT40 XP 采用“设备查找器”解决方案,即使电池在一段时间后耗尽,也能轻松定位丢失或错放的设备。这有助于保护您的投资并实现运营效率。CT40 XP 采用坚固的封装和保护套,可承受 1.8 米高处的反复跌落,提供可靠、安全的多年性能,很大限度地提高投资回报。霍尼韦尔CT40 XP 集成了功能强大的高通®处理器,可轻松升级到 Android™ 11,并符合 Android Enterprise Recommended (AER) 的要求。
霍尼韦尔CT40 XP盘点手持终端特性
Mobility Edge 企业管理工具允许公司一次性测试和验证应用、加速整个企业的部署、优化设备性能、简化维护并延长产品生命周期。
借助霍尼韦尔创新的 FlexRange 扫描成像器、13 兆像素自动对焦相机和 8 兆像素前置相机,您可以从几厘米到 10 米(32.8 英尺)准确地获取数据。
凭借第二个 BLE 信标,您可轻松定位丢失的设备,防止损失生产率,即使电池耗尽时也能如此。包括电池热插拔功能,实现不间断运行。
实现人体工学和坚固性的平衡。借助保护套,可进一步避免磨损。易于充电,不用取下硬保护套。
与霍尼韦尔连接的应用程序以及第三方应用程序(例如,MDM、Push to Talk 和 VoIP 软件)轻松兼容并无缝集成,以很大程度地提高效率并保护您的投资。
霍尼韦尔CT40 XP盘点手持终端技术参数
MECHANICAL | |
Dimensions | 162 mm x 77 mm x 18.2 mm(6.4 in x 3.0 in x 0.7 in) |
Weight | 289 g (10.1 oz) with battery pack |
Display Size | 12.7 cm (5.0 in) |
Resolution | High Defnition (1920 x 1080) |
Backlight | LED |
Touchscreen | Multi-touch capacitive,Corning® Gorilla Glass® 5 |
Hard Keys | Volume up/down key, left/right scan, power button, push to talk button |
Soft Key | On-screen scan button,reprogrammable into an application quicklaunch key |
Audio | 3.5 mm jack (available on Wi-Fi version only), PTT, VoIP ready, speaker,HAC-compliant |
I/O Ports | Durable, custom IO connector,USB Type C |
ENVIRONMENTAL | |
Operating Temperature | -20°C to +50°C(-4°F to +122°F) |
Storage Temperature | -30°C to +70°C(-22°F to +158°F) |
Humidity | 5% to 95% (non-condensing) |
Drop | Multiple 1.2 m (4 ft) drops to concrete at -10°C to +50°C (+14°F to +122°F).Multiple drops from 1.8 m (6 ft) to concrete per MIL-STD-810G with rubber boot |
Tumble | 1,000 times at 0.5 m (1.6 ft) |
ESD | ±8 kV direct; ±15 kV air |
Environmental Sealing | Independently certifed to meet IP67 and IP65 standards for moisture and particle intrusion |
SYSTEM ARCHITECTURE | |
Processor | 2.2 GHz Qualcomm®Snapdragon? 660 octa-core |
Memory | 4 GB DDR4x RAM, 32 GB Flash |
Operating System | Starts with Android 9.1;upgradable through Android 12 and 13 |
Default Language | World Wide English |
Storage Expansion | User-accessible microSD card up to 512 GB (SDXC/SDHC/SDIO-compliant) |
Battery | Li-Ion, 3.85 V, 4020 mAh; smart battery with integrated diagnostic tools,super capacitor |
Hours of Operation | 12+ hours (depends on use) |
Scan Engine | Honeywell FlexRange, N6703 Slim Imager 1D/2D barcode symbologies,Honeywell SDKs for Android |
Application Software | Honeywell utilities and demos |
Camera | 13-megapixel color camera with autofocus, 8-megapixel front-facing camera |
Sensor | Ambient light sensor, proximity sensor, accelerometer, gyroscope |
WARRANTY | |
One-year factory warranty | |
WIRELESS CONNECTIVITY | |
WWAN | WWAN Radio (ATT/VZW/SPRINT/TMO/NA/EU) LTE Advanced Support Up to 400 Mbps CAT13 LTE downlink Up to 75 Mbps CAT5 LTE uplink |
LTE (FDD) | Bands 1, 2, 3, 4, 5, 7, 8, 12, 13,17, 19, 20, 25, 26, 28, 29 |
LTE (TDD) | Bands 38, 39, 40, 41 |
UMTS/HSPA+ (3G) | Bands 1, 2, 4, 5, 6, 8, 9, 19 GSM/GPRS/EDGE Quad-Band(850/900/1800/1900 MHz) |
1xRTT/EV-DO | Bands BC0, BC1, BC10(B26BW) |
WLAN | IEEE 802.11 a/b/g/n/ac;Wi-Fi certifed, 2*2 MIMO |
Additional WLAN Features | 802.11 d/e/h/i/k/r/u/w |
WLAN Security | OPEN, WEP, WPA/WPA2(Personal and Enterprise) |
Supported EAP | TLS, PEAP, TTLS, PWD,LEAP CCX Version 4 certifed |
Bluetooth® | V5.0 Bluetooth and second BLE supported |
Bluetooth Profles | HFP, PBAP, A2DP,AVRCP, OPP, SPP, GATT |
NFC | Integrated Near Field Communication |
VPN | IPSec V4/L2TP, PPTP |
Push to Talk (PTT) | Supported |
GPS Supported Protocols | Simultaneous GNSS Receiver Support for GPS, GLONASS,Galileo and BeiDou |
*Specifcations are subject to change without notice.
